1 To 3 Solar Y Branch Cable Harness PV Wire
  • 1 To 3 Solar Y Branch Cable Harness PV Wire

1 To 3 Solar Y Branch Cable Harness PV Wire

Model Number: HY-SY4-01

Type: Y-type four-way splitter harness, 1 to 3

Conductor Material: Tinned copper

Insulation Material: XLPE

Rated Voltage: DC 1500V

Rated Current: 30A

Degree of Protection: IP67

Operating Temperature: -40°C ~ +90°C

Standard Length: 300mm (custom length available)

Payment Terms: T/T, PayPal

Lead Time: About 2 weeks

    The Y-type four-way solar cable harness is a 1 to 3 branch PV cable widely used for parallel connection of solar panels. The sealed junction body distributes one input line to three output branches, keeping the wiring of photovoltaic strings neat and secure. With tinned copper conductors and XLPE insulation, the harness withstands harsh outdoor conditions and delivers low contact resistance at DC 1500V. Cable length, wire section and connector style can be customized according to project requirements.
